Baileigh DP-1000VS 1″ Inverter Driven Drill Press

Baileigh 1 Inverter Driven Drill Press - DP-1000VSBaileigh DP-1000VS 1″ Inverter Driven Drill Press is a variable speed drill press that delivers impressive performance even it runs on the full capacity. Of course, it will last years after years without any doubts. This is not a pulley drill press but it is a high quality 16-inch drill press which is good for most of the tooling related works at impressive speed. It can surely fit your application and will surely increase tooling life.


Features:

  • The inverter driven head drill machine comes with the drilling capacity of one-inch steel.
  • Auto-reversing tap comes with a tapping capacity of 5/8-inch steel.
  • Supported speed ranges from 150 to 3000 rpm
  • It comes with wide steel column to get rid of flexing even drilling at the full capacity.
  • The drill head features a safety shield to protect you and the halogen light is good to illuminate the working area.
  • It also has a coolant system, which is an advanced feature that can’t be found with most of the drill presses.
  • One-year of warranty and lifetime technical support by phone
  • Features 2-hp motor that requires 220-volt single-phase power, which can be used in most of the shops.

Specifications:

  • Table Size: 18.1″ x 14.2″
  • Shipping Weight: 579 lbs.
  • Power: 220V Single Phase
  • Main Motor: 2 hp
  • Tapping Capacity Steel: 5/8″
  • Item Number: DP-1000VS
  • Spindle Taper: MT 3
  • Quill Diameter: 2.44″
  • Drill Capacity Steel: 1″
  • Spindle Nose to Base: 45.3″
  • Spindle Travel: 5.3″
  • Table Slot: .625″
  • Spindle Nose to Table: 23.8″
  • Spindle Speed: 150 – 3000 rpm
  • Base Dimensions L x W: 27″ x 19″
  • Shipping Dimensions: 48″ x 44″ x 82″
  • Drill Capacity Cast Iron: 1.25″
  • Tapping Capacity Cast Iron: 3/4″
  • Column Diameter: 3.62″
