Increased drilling versatility with variable spindle-to-column swing
Swing easily adjusts from 4″ to 13″ allowing center-drilling on 26″-diameter object
Spindle tilts to 90-degrees L/R, table tilts 45-degrees L/R, 4″ spindle travel
Heavy-duty 1/2 HP commercial-grade motor, 5 speeds from 480 – 3550 RPM
1/2″ chuck with MT2 taper spindle
Product Description An outstanding value in a well-built radial drill press. Overall dimensions: height 28-1/2″, top width 6-1/2, base 13″L x 5″W, 5″ support fence for stability. Table size 9″W x 8″L, base size 13″L x 8-3/4″W. Maximum distance to table 9″ (spindle), 7″ (chuck); maximum distance from spindle end to table surface 10-1/2″. 64 lbs.
Machine tool capacity and performance combined with power tool adaptability and versatility
Extra drilling capacity allows you to take the drill right to the work
Built in jackshaft assembly provides 16 different speeds from 175 rpm to 8,200 rpm
Head tilts a full 45 degree right or left with easy-to-read head tilt angle scale that permits setting of head at exact angle
Big cast-iron machined table has four T-Slots and oil trough tapped to accommodate 1/2-inch pipe; 42-inch column for extra spindle nose to table capacity and a big 6-inch quill stroke with a ram travel of 17-inch
Amazon.com Product Description The DELTA 15-126 15-inch RAM Radial Drill Press Single Phase provides the versatility of a power tool with the capacity and performance of a machine tool. The drill features a 1/2 HP single-phase motor and provides a range of 16 different speeds that vary from as low as 175 RPM up to 8200 RPM. The large 26 x 18-inch table is made of cast iron and provides four T-Slots and an oil trough that can handle a half-inch pipe. The head tilts 45-degrees in either direction, and has an easy-to-read scale. With a 42-inch column, the press has extra spindle nose to table capacity, and has a six-inch quill stroke with a ram travel of 17 inches. The press is smartly designed with convenient controls such as an adjustable quill return spring, quill lock knob, and more. The 15-126 includes six-inch spindle travel, No. 2 MT spindle, 42-inch column, 65-863 floor stand, head, jackshaft assembly, ram, cradle, column, table, raising mechanism, belt guards, motor pulley, 49-287 V-belt, 49-105 V-belt, motor and controls.
The power train gears and spline shaft are made of the finest quality, heat treated and ground nickel-chrome steel, giving extra strength and smoothness to high torque loads
The spindle is made of the finest case hardened steel for extra strength and wear
The spindle is supported by double row taper roller and thrust ball bearings at the nose, with thrust and radial axis bearings at the top
The spindle is built to withstand exceptionally heavy drilling and boring loads and to insure maximum accuracy
9″ x 48″ Carlton Radial Drill available at industrialmachinery.com. Call 614-464-4376 for an incredible deal on this American Made geared head heavy duty radial drill! Great Condition well maintained.
www.wigglesworth.com FOR SALE: ONE (1) USED 5′ x 13″ GIDDINGS & LEWIS BICKFORD RADIAL ARM DRILL PRESS MODEL: CHIPMASTER SPECIFICATIONS: ARM LENGTH…………………………………. 5′ COLUMN DIAMETER…………………………….. 13″ MINIMUM DISTANCE, FACE OF COLUMN TO SPINDLE……. 12 1/8″ MINIMUM SSPINDLE RADIUS……………………… 21 1/4″ HORIZONTAL TRAVERSE OF HEAD ON ARM……………. 3′ 11 7/8″ MAXIMUM SPINDLE RADIUS………………………. 5′ 9 1/8″ MINIMUM DISTANCE, SPINDLE TO BASE…………….. 11 1/2″ VERTICAL TRAVERSE OF SPINDLE IN HEAD………….. 20″ VERTICAL TRAVERSE OF ARM ON COLUMN……………. 2′ 6 1/2″ MAXIMUM DISNTACE, SPINDLE TO BASE…………….. 5′ EXTREME HEIGHT OF HEAD ABOVE FLOOR……………. 10′ 10″ EXTREME HEIGHT OF COLUMN ABOVE FLOOR………….. 8′ 9″ WORKING SURFACE OF BASE……………………… 3′ 6″ X 5′ 11″ POWER FEED RANGE (18)……………………….. .004-.125 IPR TAP LEADS………………………………….. 8, 11 1/2, 14, 18, 20 & 27 TPI SPINDLE SPEEDS (36)…………………………. 10-1250 RPM MORSE TAPER IN SPINDLE………………………. NO. 5 SPINDLE NOSE DIAMETER & LENGTH……………….. 3 15/16″ X 7 1/8″ DIAMETER OF SPINDLE, LEAST SECTION……………. 2 1/2″ APPROXIMATE FLOOR SPACE……………………… 11′ 10″ X 16′ 11″ APPROX. WEIGHT OF MACHINE WOTHOUT TABLE……….. 15200 LBS EQUIPPED WITH: L TYPE BASE POWER CLAMPING TO ARM & COLUMN POWER ARM …
